Cartridges in Printer: Where Are They Located and How Do You Remove Them?
Cartridges in a printer are usually located behind an access door, front cover, or top section, depending on the printer design. Inkjet cartridges often sit in a movable carriage, while laser toner cartridges may connect to a drum assembly. Always stop printing and follow the exact model instructions before removal.
Where Are Cartridges Located in a Printer?
Printer cartridges are usually found behind a dedicated cartridge-access door, front cover, or top cover.
The exact location depends on the printer’s design. HP inkjet instructions commonly direct users to open a cartridge-access door and wait for the carriage to stop moving. Brother laser models commonly place toner behind the front cover and may require removal of the toner-and-drum assembly.
Simple definitions:
- Printer cartridge: A replaceable supply containing ink or toner.
- Ink cartridge: A cartridge containing liquid ink for an inkjet printer.
- Toner cartridge: A cartridge containing powdered toner for a laser or LED printer.
- Carriage: The mechanism that holds and moves ink cartridges in many inkjet printers.
- Drum unit: An imaging component that works with toner in many laser printers.
These differences explain why there is no single cartridge location or removal method for every printer.
How Can You Find the Cartridge Access Area?
Look for a labeled access door or cover, then consult the printer manual before opening unfamiliar panels.
On many HP inkjet printers, opening the cartridge-access area exposes a movable cartridge carriage. HP tells users to wait until that carriage stops before handling the cartridges.
Brother laser printers can work differently. Several Brother models require the front cover to be opened before the toner-and-drum assembly becomes accessible.
A safe search sequence is:
- Check the printer display for instructions.
- Locate the top or front access cover.
- Look for a cartridge symbol or label.
- Check the exact printer model number.
- Consult the manufacturer’s manual if the cartridge is not immediately visible.
Do not force a panel that does not open normally.
Where Are Ink Cartridges Located in an Inkjet Printer?
Ink cartridges are commonly installed in a carriage accessible through the printer’s cartridge door or lid.
HP’s current support instructions tell users to open the cartridge-access area and wait until the carriage stops before proceeding.
Depending on the model, the cartridges may be:
- Near the center after the carriage moves into position.
- Under the scanner section of an all-in-one printer.
- Behind a front access panel.
- In dedicated side compartments on some professional printers.
For example, HP’s instructions for some DesignJet printers place ink cartridges behind covers on the left or right side.
Location is therefore model-specific.
Where Are Toner Cartridges Located in a Laser Printer?
Toner cartridges are commonly located behind a front or top cover and may be attached to a separate drum assembly.
Brother’s HL-B2080DW instructions require the user to open the front cover and pull out the combined toner-cartridge and drum-unit assembly.
Some color laser printers use a larger drum assembly containing several toner cartridges. Brother’s HL-L9310CDW, for example, uses separate black, cyan, magenta, and yellow toner positions.
Never assume the first removable component is the toner itself.
What Is the Difference Between Ink and Toner Cartridges?
Ink cartridges contain liquid ink, while toner cartridges contain powder used by laser or LED printing systems.
The two cartridge types also sit in different printer mechanisms.
| Feature | Ink Cartridge | Toner Cartridge |
|---|---|---|
| Printing material | Liquid ink | Toner powder |
| Printer type | Inkjet | Laser or LED |
| Common location | Movable carriage | Front/top compartment |
| May connect to drum | Generally no | Often |
| Typical colors | Black and color cartridges | Black or CMYK |
| Removal method | Release from carriage | May detach from drum |
The distinction matters when searching for removal instructions.
How Do You Remove an Ink Cartridge From a Printer?
Open the cartridge-access area, wait for the carriage to stop, release the required cartridge, and carefully remove it using the method specified for your printer.
HP specifically warns users not to remove an ink cartridge while the printer is actively printing. HP also recommends waiting until the carriage has stopped before removing slide-in cartridges.
Should You Turn the Inkjet Printer On Before Opening It?
Many inkjet models should be turned on before cartridge removal because the printer positions the carriage for access.
HP’s replacement procedure for several inkjet models begins by turning the printer on before opening the access door.
However, model instructions take priority.
Do not assume the same power procedure applies to every printer.
Should You Wait for the Cartridge Carriage to Stop?
Yes, you should wait until the carriage has stopped moving before touching cartridges on models that use a movable carriage.
HP explicitly includes this step in its current cartridge replacement guidance.
Trying to grab a moving carriage can interfere with the printer’s mechanism.
Wait until it becomes quiet and stationary.
How Do You Release an Ink Cartridge?
The cartridge may release by pressing it, lifting a latch, or using another model-specific locking mechanism.
For HP’s slide-in cartridge design, users press the front of the cartridge to release it.
Other HP models instruct users to press downward on a cartridge before pulling it toward themselves.
This is why generic advice such as “just pull the cartridge out” can be risky.
How Do You Remove a Toner Cartridge From a Laser Printer?
Open the correct printer cover and carefully remove the toner or toner-and-drum assembly according to the model’s instructions.
Brother’s 2022 instructions for the HL-5585D tell users to open the front cover and remove the complete toner-and-drum assembly. The toner can then be released by pressing the green lock lever.
A common Brother-style sequence is:
- Make sure the printer is in the required power state.
- Open the front cover.
- Pull out the toner-and-drum assembly.
- Place it on a clean surface.
- Locate the toner locking lever.
- Release the toner.
- Lift the cartridge from the drum.
Not every laser printer follows this sequence.
Why Might the Toner Cartridge Come Out With a Drum Unit?
Some laser printers use separate toner and drum consumables that physically connect during normal operation.
Brother documents printers where users remove the toner-and-drum assembly together before separating the two parts.
The toner cartridge contains the printing material.
The drum performs a separate imaging function.
This design means removing the assembly does not necessarily mean the drum needs replacement.
Only replace the component indicated by the printer and manufacturer instructions.
How Do You Remove Cartridges From a Color Laser Printer?
A color laser printer may require access to separate black, cyan, magenta, and yellow toner cartridges.
Brother’s HL-L9310CDW uses four toner positions identified as BK, C, M, and Y. The toner cartridges are installed in a drum assembly and individually removed from their positions.
The abbreviations mean:
- BK: Black
- C: Cyan
- M: Magenta
- Y: Yellow
Check which color the printer identifies before removing a cartridge.
There is usually no reason to remove all four just because one color needs replacement.
What Should You Do Before Removing Cartridges From a Printer?
Stop active printing, identify the correct cartridge, and check the manufacturer’s instructions before touching internal components.
HP specifically warns against removing an ink cartridge while printing. Brother recommends placing toner-and-drum assemblies on disposable paper on models where toner could accidentally scatter.
Before removal:
- Identify the printer model.
- Read the warning on the display.
- Confirm which cartridge needs attention.
- Check the manufacturer’s instructions.
- Prepare a clean work surface.
- Keep a replacement ready when appropriate.
These steps are especially useful for people replacing a cartridge for the first time.
What Parts of a Printer Cartridge Should You Avoid Touching?
Avoid touching electrical contacts, ink outlets, imaging surfaces, and other areas the manufacturer marks as sensitive.
HP tells users to avoid touching the inserted end of certain ink cartridges because ink may remain on the connection. Brother also warns users against touching specified areas of toner and drum components during removal.
Hold cartridges by their intended handles or plastic body whenever possible.
Follow the diagrams for your exact printer.
Why Won’t a Cartridge Come Out of the Printer?
A cartridge may remain locked because its release mechanism has not been activated or the printer is not in the correct cartridge-access state.
HP slide-in cartridges, for example, require pressure on the cartridge front before they release. Brother toner cartridges can require a lock lever to be pressed before they separate from the drum.
If a cartridge seems stuck:
- Do not pull harder.
- Check for a release lever.
- Check for a latch.
- Verify that the printer has stopped moving.
- Recheck the manual.
- Confirm that you are removing the correct component.
Excessive force can turn a simple cartridge change into a printer repair.
Why Might a Printer Not Recognize a Cartridge After Reinstallation?
A printer may fail to recognize a cartridge when it is not fully seated or installed according to the required locking mechanism.
Brother states that a toner cartridge must lock correctly into the drum on models using a separate drum assembly.
HP similarly instructs users to push applicable ink cartridges into their color-coded slots until they click into place.
If recognition fails, remove and carefully reinstall the cartridge according to the model’s official procedure before assuming the cartridge is defective.
Should Home Users Remove Cartridges Differently From Office Users?
No, cartridge removal depends on the printer model rather than whether the printer is used at home or at work.
The surrounding workflow can differ.
What Should a Home User Check Before Removing a Cartridge?
Home users should confirm the exact printer model and replacement cartridge before removing the existing supply.
This reduces the chance of leaving the printer without a usable cartridge.
HP recommends removing certain ink cartridges only when you are ready to insert another one.
Keep the replacement cartridge nearby before beginning.
What Should a Small Office Do With Several Printer Models?
Small offices should keep a simple list matching each printer to its correct ink or toner cartridge.
Cartridge designs can differ even within the same manufacturer.
A useful inventory might contain:
Printer model → cartridge number → ink or toner → storage location
This makes replacements faster and reduces incorrect ordering.
What Should IT Teams Do With Cartridges During Printer Upgrades?
IT teams should inventory unused cartridges before retiring or replacing printers.
A fleet upgrade can leave unopened cartridges that no longer fit active equipment. Toner Connect identifies printer replacements and office changes as common reasons businesses accumulate surplus OEM toner.
Record the exact cartridge model and quantity before clearing the supply room.
Does Cartridge Location Change in Large Office Printers?
Yes, larger business printers can place cartridges in locations that differ substantially from small desktop printers.
Some HP DesignJet models place ink cartridges behind dedicated covers on one or both sides of the printer.
Business laser printers can use large pull-out drum assemblies.
Brother’s HL-L9310CDW requires the drum unit to be pulled forward before individual toner cartridges can be accessed.
Users in corporate offices, schools, print rooms, and design studios should therefore use instructions for the exact device.
What Current Cartridge Facts Are Useful in 2026?
Current manufacturer guidance shows that cartridge access and removal procedures remain highly dependent on printer architecture.
HP’s current support guidance covers several cartridge mechanisms rather than prescribing one universal removal process. Brother’s support documentation likewise shows different procedures for monochrome and color laser printers.
Three useful facts are:
- Some ink cartridges release directly from a movable carriage.
- Some toner cartridges must first be removed with a drum assembly.
- Some color laser printers contain four separate toner cartridges.
These are design differences rather than user preferences.
What Should You Do With a Used Cartridge After Removing It?
Used cartridges should follow an appropriate manufacturer return, remanufacturing, or local recycling pathway when available.
The correct option depends on cartridge type, manufacturer, and location.
Do not confuse an empty cartridge with unopened surplus toner.
An empty cartridge has already been used.
An unopened OEM cartridge may still be usable inventory.
What Should You Do With an Unused Cartridge From an Old Printer?
Keep, transfer, sell, or appropriately recycle an unused cartridge depending on its compatibility, condition, and type.
Printer upgrades sometimes leave offices with factory-sealed toner that no longer fits active equipment. Toner Connect‘s August 24, 2026 guide recommends identifying the exact model, confirming OEM status, checking factory seals, and documenting box condition before offering unused toner for resale.
For qualifying factory-sealed OEM toner, Toner Connect provides a toner buyback service.
Toner Connect should not be used as a disposal route for the used cartridge you just removed.
What Are the Most Common Questions About Cartridges in Printers?
Most cartridge questions involve location, safe removal, cartridge recognition, and differences between ink and toner designs.
The correct answer usually depends on the exact printer model.
Can You Pull a Cartridge Straight Out of a Printer?
Sometimes, but you should never assume that pulling is the correct release method.
Certain HP cartridges require pressing or releasing the cartridge before removal. Brother toner can require a lock lever before the toner separates from its drum.
Never force a cartridge.
Do You Need to Turn Off a Printer Before Removing Cartridges?
Not always, because some manufacturers specifically require the printer to remain on during cartridge replacement.
HP’s ink-cartridge procedure for several models starts with the printer turned on. Brother’s HL-5585D toner replacement procedure also starts with the machine turned on.
Follow your exact model’s instructions.
Can You Remove a Cartridge While the Printer Is Printing?
No, you should wait until active printing has stopped before attempting cartridge removal.
HP explicitly warns users not to remove an ink cartridge during printing.
For inkjet printers with moving carriages, wait until the carriage has stopped as well.
Are All Cartridges in the Same Place?
No, cartridge location varies significantly among printer types and models.
Ink cartridges can sit in a moving carriage.
Toner cartridges may sit inside a removable drum assembly.
Professional printers can place cartridges behind dedicated side panels.
What Is the Safest Way to Remove Cartridges From a Printer?
Identify the printer model, stop active printing, open the correct access area, use the intended release mechanism, and remove only the cartridge that needs attention.
Inkjet and laser printers can use very different cartridge systems. HP documents carriage-based ink removal, while Brother documents laser printers where toner must first be removed with a drum assembly.
The most important rule is simple: if a cartridge does not release normally, do not force it. Check the manufacturer’s instructions for your exact model before continuing.
